| PF400S Pre-Filter Section |
| Laser filter exhaust pre-filter section |
 |
| |
| What is it? |
| |
| We call it a Pre filter section. It is designed specifically for the laser or engraver end user. It is essentially a motor less or passive series of filters that can enhance the performance of an SPH 400 by giving it significant extra dust and particle capture. It can be used as a self contained system beside the fume extractor or attached directly on top of the SPH-400, doubling the height and the total filter capacity. |
| |
| Who needs it? |
| |
| Customers that have heavy dust loadings will appreciate this pre-filter section since it will prolong the life of the primary filters inside the SPH-400 series of extractors as well as reduce the life cycle of filter changes. |
|
|
| |
| What's inside? |
| |
| The SPH-400 ships with a simple pleated PRE filter to protect both the HEPA and the carbon filter from being plugged with large dust and particulate matter. With the addition of the pre-filter section you now have two huge 12” x 6” x 24” antimicrobial dust filter bags that can capture a significant amount of dust and particulate matter. |
| |
| How easy is to change the filters? |
| |
| How easy is it to change the filters? Whether you have a standalone section or a direct mount section the filter bags are accessed in the same manner. Remove inlet cover, quarter turn 4 locking mechanisms and remove the section to replace bags. Designed to be clean simple and effective. Dust is contained in the bags to minimize the mess and exposure of personnel to potentially harmful dust. |
|
 |
| |
| How can I use it? |
| |
| On the left is the pre-filter unit on it’s own and on the right it is mounted on top of an SPH-400. The stand alone section is versatile enough to be used with any existing filter system. The inlet and discharge collars can accommodate many different arrangements to suit the application. Single or dual 1”, 1.5”, 2”, 2.5”, 3” or 4” diameter collars are available as standard options. Custom diameters are available upon request |
| |
| Can I install this myself if I have an SPH400? |
| |
| If height is not an issue, the installation is quite simple and straight forward. Remove the inlet cover of the SPH-400 system. The pre-filter section clamps directly onto the unit. Replace the cover and clamp onto the pre-filter section . You are now ready to go |
|
|
|
|
|
|
|
| |
 |
|
 |
|
|
